Table A-1. RabbitCore RCM3000 Specifications
Feature
RCM3000
RCM3010
Microprocessor
EMI Reduction
Ethernet Port
Rabbit 3000 at 29.4 MHz
Spectrum spreader for reduced EMI (radiated emissions)
10/100-compatible with 10Base-T interface, RJ-45, 2 LEDs
Flash Memory
SRAM
512K (2 × 256K)
512K
256K
128K
Backup Battery
General-Purpose I/O
Additional Digital Inputs
Additional Digital Outputs
Auxiliary I/O Bus
Serial Ports
Serial Rate
Slave Interface
Real-Time Clock
Timers
Watchdog/Supervisor
Pulse-Width Modulators
Input Capture
Quadrature Decoder
Power
52
Connection for user-supplied backup battery (to support RTC and SRAM)
52 parallel digital I/0 lines:
? 44 configurable I/O,
? 4 fixed inputs,
? 4 fixed outputs
2 startup mode, reset in
Status, reset out
8 data lines and 6 address lines (shared with I/O) plus I/O read/write
6 shared high-speed, CMOS-compatible ports:
? 6 configurable as asynchronous (with IrDA),
4 as clocked serial (SPI), and 2 as
SDLC/HDLC (with IrDA)
? 1 asynchronous serial port dedicated for
programming
? support for MIR/SIR IrDA transceiver
Max. asynchronous baud rate = CLK/8
A slave port allows the RCM3100 to be used as a master or as an
intelligent peripheral device with Rabbit-based or any other type of
processor
Yes
Ten 8-bit timers (6 cascadable from the first),
one 10-bit timer with 2 match registers
Yes
10-bit free-running counter and four pulse-width registers
2- channel input capture can be used to time input signals
from various port pins
2-channel quadrature decoder accepts inputs
from external incremental encoder modules
3.15 V to 3.45 V DC
150 mA @ 3.3 V
RabbitCore RCM3000
